Who Invented The Corvette Head-Up Display? | Corvette Display CORVETTE TODAY #218
May 9, 2025
To learn more about who invented the Corvette head-up display and the Corvette display, please feel free to visit our YouTube channel.
This video covers who invented the Corvette head-up display, along with the following subjects:
- Origins of the head-up display in cars
- How the head-up display was developed for Corvette
- Corvette innovation
**********************
I don't know about you, but I love having a Head-Up Display in my Corvette!
But did you know that the HUD's didn't come into existence
for Corvette until the C5 era?
On this episode of CORVETTE TODAY, you'll meet Steve Stringfellow, the inventor of the Corvette Head-Up Display! Steve joins your CORVETTE TODAY host, Steve Garrett, to talk about the origins of the Head-Up Display and what it took to actually get it into Corvette and the trials and tribulations thereof.
It's a fascinating episode...get up close and personal with the inventor of the Corvette HUD, Steve Stringfellow!
********************
